Mantall XE80W RT – 8m

The Mantall XE80W RT electric scissor lift is designed for working on uneven surfaces. The lift has hydraulic self-levelling legs, which allow the user to automatically level the machine on slopes up to 4.5 degrees lengthwise and up to 10 degrees widthwise.

This scissor lift has a working height of up to 8 meters with a maximum load capacity of 550 kg.

The lift also has a number of safety features for safe operation such as a dedicated control and self-diagnosis system, as well as joystick with proportional control for lifting and traveling that makes the lift very easy to use.

Saada taotlus
Working height max H1

8 m

Platform height max H2

6 m

Platform extension

1 m

Lifting capacity

550 kg

Lifting capacity on the extension

120 kg

Max. platform occupancy

2 pers

Dimension of the platform B*C*A

2.3 × 1.15 × 1.1 m

Length and width E*F

2.55×1.2 m

Height D

2.25 m

Height-guardrails folded M

1.64 m

Wheelbase G

1.68 m

Ground clearance H

0.15 m

Turning radius-inside
Turning radius-outside

2.4 m

Raising time/lowering time

32/30 s

Drive speed-stowed

3.4 km/h

Drive speed-raised

0.7 km/h

Gradeability

35%

Tilt (front to back/side to side)

3° / 2°

Outrigger level ability-front to back

4.5°

Outrigger level ability-side to side

10°

Tire size

406×152 mm

Power source

4×6V/225Ah

Kaal 2270 kg
Mõõtmed 255 × 120 × 225 cm
Standard Features
  • Battery powered
  • Proportional driving
  • 4WD
  • Slide out on platform
  • Foldable railing
  • Non-marking wheels
  • Automatic braking system
  • Emergency lowering
  • Emergency stop
  • Self-diagnosis system
  • Tilt sensor with alarm
  • Hour counter
  • Forklift pockets
  • Warning light
  • Integrated battery charger
  • Automatic leveling of hydraulic outriggers
  • Maintenance-free battery
  • CE-marked
